HBEP Electro Permanent Lifting Magnet with Battery Supply for Steel Parts from 500-5000kg

HBEP Series Electro Permanent Lifting Magnet with Battery Supply
for Flat and Round Steel Parts from 500-5000kg

Thanks to the integrated rechargeable battery group, this revolutionary electro permanent lifting magnet functions completely autonomously.

A power supply cable is not required.

Electric current pulse is only used to invert the magnet molecularly; the effective force is generated by permanent magnets.

No power consumed during working, energy saving.

Due to the low power consumption, the battery has an autonomy of over 700 cycles.

Charging the battery by means of the built-in charger (230V / 50Hz) takes about 5 to 8 hours, depending on the model.

NEW: Automatic cycle for fast unloading of cutting machines.

SEND INQUIRY

A Much Safer Type of LIFTING MAGNETS

Model Rated Lifting Force (kg) Min. Plate Thickness (mm) Working Voltage
(kg)
Recharge Time (H) Overall Dimension (mm) Weight (kg)
A A1 B B1 H
HBEP-005 500 6 DC24 6-8 474 276 404 152 457 92
HBEP-010 1000 6 DC36 7-8 510 322 418 170 497 126
HBEP-015 1500 10 DC48 7-8 624 436 446 208 491 173
HBEP-020 2000 12 DC48 7-8 672 484 446 228 533 206
HBEP-030 3000 16 DC60 8-9 732 532 547 312 535 268
HBEP-050 5000 20 DC72 8-9 1332 1136 547 243 557 493
